Chart Recorder:
The chart recorder keeps a running log of each test. This is an optional
feature and may not be included with your equipment.
Refer to the manufacturer documentation for more information.
Switches:
- MOTOR: Sets control of the motor When set to MANUAL, the motor
will turn at 150 RPM until stopped. When set to AUTOMATIC, the
motor will turn according to the parameters of the test that is currently
running. If no test is running, the motor will be stopped. When set to
OFF, the motor will not turn at all.
- DC VOLT: Controls power to the potentiometer. The potentiometer
should be turned off when there is no oil in the cell to prevent it from
overheating.
- CYLINDER: Controls the ow of oil into the cell. When FILL is
selected, oil ows into the cell for testing. When DRAIN is selected, oil
ows out of the cell and back into the reservoir.
- PUMP: Controls power to the pump. The pump adds pressure to the
cell as long as this switch is set to MANUAL. When AUTOMATIC is
selected, the pump is controlled by the electronic control board.
When OFF is selected, the pump will not run at all.
- HEAT: Controls power to the heaters. The heaters are controlled by
the electronic control board. Turning this switch on gives heat control
to the control board.
- COOL: Controls the cooling system. The cooling system is on and
cooling the cell as long as this switch is set to MANUAL. When
AUTOMATIC is selected, the cooling system is controlled by the
electronic control board. When OFF is selected, the cooling system
will not run at all.
- AIR TO CYLINDER: When this switch is on, air enters the cell and
forces the oil out into the reservoir.
- CHART RECORDER: Controls power to the chart recorder.
- MAIN: Controls power to the entire system. When this switch is off, all
other electronic systems in the Consistometer are also off.
