Specications
Size 22.5" × 27.5" × 70"
Weight Approximately 450 lb
Crated Size 26" × 34" × 76"
Crated Weight Approximately 750 lb
Temperature Controller Digital with 0.1° Resolution
Pressure Indicator Digital transducer with 1 PSI (0.1 MPa)
resolution. Analog gauge.
Slurry Cup Variable Speed: 0 – 300 RPM
Max Temperature (For tests above 400°F, refer to page 15)
Model 2025 400°F (204.4°C)
Model 2040 600°F (315.5°C)
Maximum Pressure
Model 2025 25,000 PSI (173 MPa)
Model 2040 40,000 PSI (276 MPa)
#120-001 Mineral Oil, 1 Gallon (For tests at or below 400°F)
#120-004 Phenylmethylsiloxane Silicone Fluid, PM-125, 1 gallon (For
tests over 400°F)
#120-00-1 Tool Kit (Includes slurry cup stand, slurry cup tool, lifting
tongs for heater shield, and lifting tongs for potentiometer)
#120-102 Rupture Disk, 28,000 PSI (193 MPa), Model 2025
#120-103 Rupture Disk, 45,000 PSI (310 MPa), Model 2040
#120-148 Retaining Ring for Cap (For Model 2025)
#120-149 O-ring for Cap, Viton (For Model 2025)
#120-201 Thermocouple, Bath (For Model 2040)
#120-203 Thermocouple, Slurry Cup (For Model 2040)
#120-208-1 Thermocouple, Slurry Cup (For Model 2025)
#120-35-004 Backup Ring for Cap (For Model 2025)
#120-35-015 Drip Tray, Stainless Steel
#120-35-033 Air Filter
#120-35-058 Chart Recorder (Optional)
#120-35-132 Oil Filter
#120-40-032 High Pressure Filter
#120-40-033 Filter Element for High Pressure Filter
#120-401 O-ring for Cell Cap, Metal
#120-401-V O-ring for Cell Cap, Viton (For Model 2040. For tests
below 10,000 PSI and below 300°F only.)
#120-35-031 O-ring for Oil Reservoir, Viton
#120-50-037 Air Regular
#120-519 Slurry Cup without Expansion Chamber, Model 2025
#120-521 Slurry Cup with Expansion Chamber, Model 2040
#120-628 Potentiometer Assembly
#120-75-10 Slotted Weight Set
#120-75-9 Weight Hanger
Components
