The Main Screen of the software shows you all of the data for the current test.
Cell Display
Elapsed Time: Elapsed time since the beginning of the test.
Pressure: Pressure currently in the test cell.
Sample Temp: The temperature inside the slurry cup.
Bath Temp: The temperature of the oil inside the test cell.
Consistency: The consistency of the slurry (in Bc).
Consistency: The raw signal from the potentiometer (Volts).
Heater Power: This is the percentage of power being output by the heaters.
Autoscroll ON/OFF: This allows the user to control display the data
manually or scroll the data automatically.
Cursor Options: Here you can change cursor settings within the graph.
a. Cursor On/Off: With this option ON, a window will open to display the
data based on the location of the cursor.
Autoscroll
ON/OFF
Cursor
Options
