Hesitation Squeeze:
- Surface Retention Time: Time period before the test begins where the
motor is on but the heater and pressure are off.
- Starting Temp: The initial temperature set point for the test.
- Time to Squeeze Temp: The amount of time (in minutes) the test will
take to heat the slurry to Squeeze Temp.
- Squeeze Temp: The rst temperature set point.
- Starting Pressure: Initial pressure for the test.
- Total Time to Final: The amount of time (in minutes) the test will take
to pressure the slurry to Final Pressure.
- Final Pressure: The pressure set point.
- Total Time to Bottom ST: The amount of time (in minutes) the test will
take to heat the slurry to Bottom Hole Static Temperature.
- Bottom Hole Static Temperature: The second temperature set point.
- Squeeze Motor On Time: The amount of time (in minutes) the motor is
on during a squeeze.
- Squeeze Motor Off Time: The amount of time (in minutes) the motor is
off during a squeeze.
- Squeeze Cycle Count: The number of times the cycle will repeat.
Copying a Test:
To copy a test into a temporary memory slot for editing:
1. Push the Scroll Wheel to access the Main Menu.
2. Scroll to option 2, “Select New Test”. Push the Scroll Wheel to select.
3. Scroll to the test you want to copy. Push the Scroll Wheel to enter.
4. Push the Scroll Wheel to access the Main Menu again.
5. Scroll to option 4, “Copy Test to Temp”. Push the Scroll Wheel to enter.
6. Select a temp slot from the list. Push the Scroll Wheel to enter.
7. Push the Scroll Wheel to access the Main Menu again.
8. Scroll to option 2, “Select New Test”. Push the Scroll Wheel to enter.
9. Scroll to the temp slot you chose in step 6. Push the Scroll Wheel to
select. The test has now been copied into a temporary slot.
