OHAUS EXPLORER PRO - 3.4.4 Percent Weighing; Percent Weighing Usage; Percent Weighing Adjustments

EN-18 Explorer Pro
3.4.4 Percent Weighing
Percent weighing allows placing a reference load on the balance,
then viewing other loads as a percentage of the reference. The
load placed on the pan as a reference is displayed as 100%.
Subsequent loads are displayed as a percentage of the reference.
The maximum limit is the capacity of the balance. The minimum
limit is 100d. The display data includes reference weight in
unit of measurement, difference value in percent, difference value
in measuring unit and a bar graph indicating present used
capacity of the balance.
PE R CENT WEIGHING 01/01/03 03:05:45 PM
R EFE R ENCE
S ET U P
NEW R EF
0.00 g
R ef: 0.00g
Diff: 0.00 %
Diff: 0.00g
*
0g
6100
g
Add R eference Weight, Press Enter
USE
PERCENT WEIGHING
With the NEW REF soft key highlighted, press the Enter button.
Place the reference weight on the pan and press the Enter
button again. The sample shown indicates a 200g weight
was placed on the pan.
PE R CENT WEIGHING 01/01/03 03:05:45 PM
R EFE R ENCE
S ET U P
NEW R EF
200.00 g
R ef: 200.00g
Diff: 0.00 %
Diff: 0.00g
*
0g
6100
g
Add R eference Weight, Press Enter
100.00
%
The reference weight is removed and a second weight is placed
on the pan. The example illustrates a 50 g weight.
PE R CENT WEIGHING 01/01/03 03:05:45 PM
R EFE R ENCE
S ET U P
NEW R EF
50.00 g
R ef: 200.00g
Diff: -75.00 %
Diff: -150.00g
*
0g
6100
g
25.00
%
ADJUSTMENTS
The PERCENT WEIGHING display contains three soft keys at the
top of the screen REFERENCE, SETUP and NEW REF.
NEW REF
When NEW REF soft key is selected, follow the screen instructions
“Add Reference Weight, Press Enter”. This establishes a new
reference weight.
SETUP
Select SETUP soft key and press the Enter button. The PERCENT
WEIGHING SETUP display is shown.
PE R CENT WEIGHING S ET U P
U nit : g
R eference : 0.00
Display S ettings : Custom
R eference Key : U nlocked
New R eference Key : U nlocked
Exit
