Microsoft Windows 86
6. Select [Have Disk] and insert your Windows XP CD-ROM. Open
the Valueadd\msft\net\netbeui folder, click the Netnbf.inf file and
then click [Open]. Now the printer has been configured and
NetBEUI has been installed; you can configure Windows to print
over the network.
Printer driver configuration
In the following example, the printer has been configured as follows:
1. Set up the printer driver as the default local printer.
2. In the [Start] menu, select [Settings] then [Printers].
3. Select the relevant printer driver, then [Properties].
4. Click on the [Details] tab in the printer driver.
5. Select [Add Port]. Select [Network] and click [Browse].
6. Double-click [Entire Network], [PrintServer] and [OL07DB85].
7. Select [Prn1] and click OK.
8. Check that [Network] is selected and click [OK].
9. Select [Apply] and [OK] to close [Properties].
> Printing can be carried out using the application software.
> The Master Browser function manages machine information from
the same Workgroup, and replies to summary requests from other
workgroups.
> The Master Browser function operates only if the Workgroup name
is PrintServer.
Computer Name: OL07DB85
Workgroup: PrintServer
Comment: EthernetBoard OKILAN
