7. Troubleshooting and repair procedure
Panel display
(The mark indicates no
message in the upper row.)
ON
LINE
lamp
Inspection
lamp
Details
Remedial
measure
Density Calibration
Error
Varies On Sensor adjustment error
Because the PU firmware does not
notice this status to the CU firmware
in the Shipping Mode even when
the PU firmware has detected this
status, this error does not occur in
the user environment
−
Registration Error <n>
Varies On Color registration correction error.
Indicates that an error has occurred
during the coarse adjustment or in
the main scanning line correction.
Because the PU firmware does not
notice this status to the CU firmware
in the Shipping Mode even when
the PU firmware has detected this
status, this error does not occur in
the user environment.
n
2=Y
3=M
4=C
5=
−
Registration Sensor
Error <n>
Varies On Color registration correction sensor
error
Because the PU firmware does not
notice this status to the CU firmware
in the Shipping Mode even when
the PU firmware has detected this
status, this error does not occur in
the user environment.
n
2=Y
3=M
4=C
5=
−
Panel display
(The mark indicates no
message in the upper row.)
ON
LINE
lamp
Inspection
lamp
Details
Remedial
measure
%COLOR% Head
Data Error
Varies On Cannot fine the correction data
for the LED head. Alternately, the
correction data for the LED head is
illegal.
Because the PU firmware does not
notice this status to the CU firmware
in the Shipping Mode even when
the PU firmware has detected this
status, this error does not occur in
the user environment.
%COLOR%
Y
M
C
K
−
%TRAY% runs out of
paper.
Varies On Indicates that the tray runs out of
paper.
Warning only is issued until the tray
that runs out paper is specified for
print.
%TRAY%
Tray 1
Tray 2
Tray 3
MP tray
Feed paper to
the indicated
tray.
The file system is full.
Varies On Indicates that the file system that has
been constructed on the recording
device (HDD/FLASH) runs out of free
space.
Because this is a temporary warning,
this warning is indicated until the
job is complete. It disappears at the
completion of the job.
Explain
user that
no remedial
measure is
required.
Writing in the file
system is prohibited.
Varies Varies Indicates that an attempt is made to
write data in the file system that has
been constructed on the recording
device (HDD/FLASH), and is
prohibited of writing data.
Because this is a temporary warning,
this warning is indicated until the
job is complete. It disappears at the
completion of the job.
Explain
user that
no remedial
measure is
required.
