Oki C710 - Maintenance Utilities

43856301TH Rev.3
93 /
Oki Data CONFIDENTIAL
5. Maintenance Menu
5.2 Maintenance Utilities
The maintenance utilities enables user to perform the adjustment shown in Table 5-2.
Details of the maintenance utilities are available in the following documents.
(1) Maintenance Utilities Operation Manual:
42678801FUOI Rev18 and higher (Japanese)
42678801FUO2 Rev18 and higher (English)
(2) The maintenance utilities programs shown below.
Applicable OS Filename Model number
Win9X/Me/NT/2000/XP
(Japanese/English)
MuWin.zip
42678801FW01 Rev18 and
higher
Table 5-2 Maintenance utilities adjustment items
Item Adjustment contents
Maintenance
Utilities
Operation
Manual item
number
Operation on the
operator panel
(Item number
corresponds to that
of the Maintenance
Manual.)
1 PU board
replacement
Copies the EEPROM data of the existing
PU board.
Adjustment objective: Copies the
EEPROM data of the existing PU board
to the new PU board when the existing
PU board needs to be replaced with the
new PU board during maintenance.
Section
2.4.1.1.1
Operation from
the operator panel
cannot be made.
2 PU serial
number
setting
Re-writing the printer serial number
saved in PU.
Adjustment objective: When copying
the EEPROM data of the PU board is
not possible (due to I/F error or others),
re-write the serial number in the new
replacement PU board.
Section
2.4.1.1.2.1
Operation from
the operator panel
cannot be made.
3 Factory/
Shipping
mode
Switching between the Factory mode and
the Shipping mode.
Adjustment objective: When copying
the EEPROM data of the PU board is
not possible (due to I/F error or others),
implement switching between the Factory
mode and the Shipping mode. When
the replacement board is supplied for
maintenance, it has been set in the
Factory mode as the default setting.
Switching from the Factory mode to the
Shipping mode needs to be performed
using this function.
Section
2.4.1.1.2.3
Section 5.3.2.10
Item Adjustment contents
Maintenance
Utilities
Operation
Manual item
number
Operation on the
operator panel
(Item number
corresponds to that
of the Maintenance
Manual.)
4 CU board
replacement
Re-writing the EEPROM setup value of
the CU board.
Adjustment objective: Re-writes the
EEPROM data of the existing CU board
to the new CU board when the existing
CU board needs to be replaced with the
new CU board during maintenance.
See note:
Section
2.4.1.1.3
Operation from
the operator panel
cannot be made.
5 Serial
number
information
setting
Re-writing the printer serial number,
selections, output mode and printer serial
number that are saved in CU.
Section
2.4.1.1.4.3
Operation from
the operator panel
cannot be made.
6 Setup
information
of board
items
Verifying the serial number information
and the Factory/Shipping mode.
Section
2.4.1.1.7
Operation from
the operator panel
cannot be made.
7 USB
software
upgrade
Upgrading the USB software Section
2.4.2.2.1
Operation from
the operator panel
cannot be made.
8 NIC software
upgrade
Upgrading the NIC software Section
2.4.2.2.2
Operation from
the operator panel
cannot be made.
9 NIC Web
Page
upgrade
NIC Web Page upgrade Section
2.4.2.2.3
Operation from
the operator panel
cannot be made.
10 Mac address
setting
Setting the Mac address Section
2.4.2.2.4
Operation from
the operator panel
cannot be made.
11 Consumable
items
counter
maintenance
function
Copies the consumable items counter
data
Drum counter (Y, M, C, K)
Fuser counter
Belt counter
Toner counter (Y, M, C, K)
Adjustment objective: Copies the data of
the respective consumable item counters
in the case when an existing consumable
item that is in the middle of its usage is
removed and installed in another printer.
Section
2.4.1.2.1
Operation from
the operator panel
cannot be made.
Note! For the CU board of the C710, replace the entire EEPROM that is installed
in CU using socket.
