2. Operating instructions
(9) Belt cleaning
The
toner left on the transport belt is cleaned up by the belt cleaning blade,
and all residual toner is collected in the waste toner box of the transport belt
unit.
Belt waste toner box
Transport belt
Belt cleaning blade
