4. Component replacement
EM-30L Class C
Latch claw patching parts
EM-30L Class C
Shaft slit side surface
EM-30L Class C
Gear tooth surfaces and end surfaces
EM-30L Class C
Gear bottom surfaces
EM-30L Class A
Sliding surfaces
EM-30L Class A
Posts
EM-30L Class C
End surfaces
EM-30L Class A
Both-ended surfaces
EM-30L Class A
Both-ended surfaces
Shaft-Hopping
Plate-Gear-HP-Caulking
Stopper-HP
Holder-Planet-HP
Gear-Planet(Z12)-HP
Gear-Z24-30-HP
Gear-Z27-48-HP
Gear-Z24-30-HP
Zoom-out
Plate-Assy.-Base
