44015503TH Rev. 1
47 /
Oki Data CONFIDENTIAL
3. INSTALLATION
3. Place the printer on the stack of additional trays.
Personal injury may occur.
Since the printer weights approximately 40 kg, it should be lifted by two or more
people.
Proceed to step 5 when one additional tray is used.
Printer
Added tray
Cabinet
Pin
Hole on the
bottom
4. Install the support plate.
Memo The plate can be installed only when two additional trays are used. It cannot
be installed for the printer main unit only when one additional tray is used.
Open the multi-purpose tray.
Align the holes on the bottom of the
printer to the pins of the additional tray.
Place the printer gently on the stack of
additional trays.
Push up the center handle (blue) to
open the front cover.
Push the OPEN button to open the top
cover.
To Next Page
