24
Print head
Capping unit
Heater
This printer is equipped with three heaters for ink fusing and image quality stabilization.
* These three heaters are controlled independently.
Head up down mechanism
By lowering the lever, the print
head position rises by 0.5mm.
Wiper blade
It removes foreign matters
on the surface of the
nozzles of the print head.
Capping unit
It prevents the nozzles of the
print head from drying.
Front Rear
Preheater
Preheats the media.
Print heater
Make the ink penetrate into the
media to fuse the ink.
After heater
Dries ink to stabilize print quality.
Media feed direction
Media
Carriage
Paper guide(rear)
Print head
