Cleaning the Machine 8-17
5 The magenta toner cartridge has
been moved to the position from
where it can be replaced.
Pull down the handle on the
toner cartridge until the toner
cartridge is unlocked and moves
out slightly toward you.
Remove the toner cartridge.
" When the magenta toner
cartridge is removed, a
gap is created within the
machine so that the print
head window can easily
be cleaned.
Note
Do not touch the contact
indicated the illustration.
To Next Page
