181
Maintenance
3
Clean the media
feed rollers by wi
p-
ing them with a soft, dry cloth.
CAUTION!
The area around the fuse
r unit is
extremely ho
t.
T
ouching a
nything other th
an the
indicated lever
s may result in burns.
If you get burned, immediately cool
the skin under cold water
, and then
seek professional medica
l attention.
BOTTOM
VIEW
180
182
