Oki MC361 User Manual

25
Switch Scan Test
Lower display shows asterisk (*) when function on upper display is unavailable
1 2 3 4
Upper Display
Detail
Lower
Display
Detail
Lower
Display
Detail
Lower
Display
Detail
Lower
Display
PAPER ROUTE : PU
Entrance
sensor 1
H: No paper
exists
L: Paper exists
Write sensor
H: No paper
exists
L: Paper
exists
Exit sensor
H: No paper
exists
L: Paper
exists
TONER SENS Toner sensor K
H: Light
shielded
L: Light
reflected
Toner Y
Sensor
H: Light
shielded
L: Light
reflected
Toner M
Sensor
H: Light
shielded
L: Light
reflected
Toner C
Sensor
H: Light
shielded
L: Light
reflected
CVO UP_LU_FU
Cover-open
switch
H - Close
L – Open
Face-up cover-
open sensor
H: Close
L. Open
REG L/R_OHP_WG
Color
registration
sensor L
AD value:
***H
Color
registration
sensor R
AD value:
***H
HT THERMISTER
Fuser
thermistor
upper
sensor
AD value:
***H
Fuser thermistor
lower
sensor
AD value:
***H
Heater frame
thermistor
AD value:
***H
HUM_TEMP_DEN 1
Humidity
sensor
AD value:
***H
Temperature
sensor
AD value:
***H
Density
sensor (K)
AD value:
***H
Density sensor
(YMC)
AD value:
***H
BELT_T Belt thermistor
AD value:
***H
ID UP/DOWN
I/D Up Down
Sns
H: Up
L: Down
TAG COLOR TAG ID
UID:
***H
TAG ID
UID:
***H
TAG ID
UID:
***H
TAG ID
UID:
***H
DISTONER
FULL_BOX
Waste toner
sensor
H: Light not
reflected
L: Light
reflected
T1 PE_PNE_CVO_CA
Tray-1 paper-
end
sensor
H: No paper
exists
L: Paper
exists
Cassette sensor
H. Cassette
exists
L. Cassette
does not
exist
T1 HOP_LIFT Hopping sensor
H: No paper
exists
L: Paper
exists
T2 PE_PNE_CVO_CA
Tray-2 paper-
end
sensor
H: No paper
exists
L: Paper
exists
T2 HOP_LF_FED
2nd-Hopping
Sns
H: No paper
exists
L: Paper
exists
Tray 2
entrance sensor
H: No paper
exists
L: Paper exists
DUP RA_FNT
Duplex rear
sensor
H: Light
shielded
L: Light
reflected
Duplex front
sensor
H: No paper
exists
L: Paper exists

Oki MC361 Specifications

Printing Specifications

print speed color	23 ppm
print speed black & white	25 ppm
time to first page color	9 seconds
time to first page black & white	8.5 seconds
print resolution	1200 x 600 dpi

Copying Specifications

copy speed color	23 cpm
copy speed black & white	25 cpm
first copy out color	14 seconds
first copy out black & white	12 seconds
copy resolution	600 x 600 dpi

Scanning Specifications

scan resolution	1200 x 1200 dpi
scan speed color	3 sec./page
scan speed black & white	2 sec./page

Fax Specifications

fax modem speed	33.6 Kbps
transmission speed	3 seconds/page
fax resolution	200 x 400 dpi

Power and Environment

power consumption operating	500W
power consumption max	1170W
power consumption idle	100W

Weight and Dimensions

size	16.8" x 20" x 17.5"
weight	63 lb.
weight with consumables	29 kg
