5. MAINTENANCE MENUS
Item1 Item2 Item3 Item4 Item5 Value
Default
value
ODA
Default
value
OEL
Default
value
JP
Notes
Password ADF
(Back-side)
Adjust Scan
Position
ADF
(Front-side)
Side Reg. +8 ~ -8 mm 0 0 0 Adjust the starting read pixel position in the horizontal scanning direction when reading
a document from the ADF.
Adjust in intervals of one step = 4/600 dpi (=0.17 mm).
Front Edge +30 ~ -30 mm 0 0 0 When reading a document from the ADF, add a value for the basic value when reading
the shadow of the front edge of the document. To skip the front edge of the document,
add a negative value.
Increase or decrease the number of motor pulses from detection by the sensor of the
front edge of the media until actual reading starts.
Adjust in intervals of one step = 4/600 dpi (= 0.17 mm).
Back Edge +30 ~ -30 mm 0 0 0 When reading a document from the ADF, add a value for the basic value when skipping
the back edge of the document. To read the shadow of the back edge of the document,
add a negative value.
Increase or decrease the number of motor pulses from detection by the sensor of the
back edge of the media until actual reading ends.
Adjust in intervals of one step = 4/600 dpi (= 0.17 mm).
ADF
(Back-side)
Front Edge +30 ~ -30 mm 0 0 0 When reading a document from the ADF, add a value for the basic value when reading
the shadow of the front edge of the document. To skip the front edge of the document,
add a negative value.
Increase or decrease the number of motor pulses from detection by the sensor of the
front edge of the media until actual reading starts.
Adjust in intervals of one step = 4/600 dpi (= 0.17 mm).
Back Edge +30 ~ -30 mm 0 0 0 When reading a document from the ADF, add a value for the basic value when skipping
the back edge of the document. To read the shadow of the back edge of the document,
add a negative value.
Increase or decrease the number of motor pulses from detection by the sensor of the
back edge of the media until actual reading ends.
Adjust in intervals of one step = 4/600 dpi (= 0.17 mm).
Adjust
ADF Scan
Position
+30 ~ -30 mm 0 0 0 Set the CIS reading position of the ADF for the focusing standard.
Adjust in intervals of one step = 4/600 dpi (= 0.17 mm). This is correlated to adjustment
of the ADF front edge position.
Adjust Mech. Adjust
Mech.
FB Drive
Current
1 ~ 140 Connect a panel or PC and set the electric current value of the scanner motor.
FB Keep
Current
1 ~ 140
ADF Drive
Current
1 ~ 140
ADF Keep
Current
1 ~ 140

Oki MC561 Specifications

Printing Specifications

Print Speed	Up to 27 ppm color, 31 ppm black & white
Time to First Page	As fast as 8 seconds in color, 7.5 seconds in black & white
Print Resolution	Up to 1200 x 600 dpi

Copying Specifications

Copy Speed	Up to 27 cpm color, 31 cpm black & white
First Copy Out	As fast as 14 seconds in color, 12 seconds in black & white
Copy Resolution	Up to 600 x 600 dpi

Scanning Specifications

Scan Type	Color and black & white flatbed
Scan Resolution	Up to 1200 x 1200 dpi
Scan Speed	Approx. 3 sec./page color, approx 2 sec./page black & white at 300 dpi

Fax Specifications

Fax Modem	33.6 Kbps Super G3
Transmission Speed	3 seconds/page
Fax Resolution	Up to 200 x 400 dpi

System Memory

Standard Imaging RAM	256 MB
Max Imaging RAM	768 MB
SD Card Storage	4 GB standard; 16 GB optional

Paper Handling

Scanner RADF Capacity	Up to 50 letter/legal sheets
Standard Input	350 sheets (250 sheets via Main Tray + 100 sheets via MPT)
Maximum Input	880 sheets (with optional 530-sheet 2nd Paper Tray)

Environmental Specifications

Size	16.8" x 20" x 17.5" (42.7 cm x 50.9 cm x 44.4 cm)
Weight	63 lb. (29 kg)
Power Consumption	Operating Normal 570W; Max 1170W; Idle 100W; Power Save 20W; Deep Sleep <1.5W
