Page #253 background imageLoading...
Page #253 background image
44473001TH Rev.1
253 /
Oki Data CONFIDENTIAL
7. TROUBLESHOOTING PROCEDURES
7.5.6 Response after Flash compulsive initialization
Explain the response after compulsive initialization is performed with trouble occurred in
Flash.
(1) Flash compulsive initialization
If Flash compulsive initialization is performed, the following data would be deleted
and the network and fax would not be available.
NIC-Firmware
WebPage data
Log data
Address data
Message data
Languagele
I
t
is necessary to write above Firmware and data into Flash by the maintenance
utility.
Note! Do not carry it out usually.
7.5.7 Copy Image Abnormality Error Troubleshooting
When the following symptom occurs in the copy image, implement the inspection and
adjustment of the copy image.
Line appears on the copy image.
Color of the copy image becomes slightly thin.
Color of the copy image becomes dark.
Color of the copy image becomes abnormal.
Print position of the copy image is shifted.
Required equipment and tools
Slide caliper gauge or scale (JIS 1st class product)
Inspection chart:Part Number : 44623501
PC (PC scan should be possible.)
Scanner inspection and adjustment tool
USB cables : 1 cable (Compliant with Rev. 2.0)
1. Identifying the problem.
Perform section 7.5.3. "Abnormal Image Troubleshooting" to identify whether the
problem is located in the printer or in the scanner.
If the cause of the problem is in the scanner, go to the next item.
2. Cleaning
Perform sections 6.6 "Cleaning Rollers in the ADF", 6.7 "Cleaning the Document
Glass" respectively.
If the cleaning cannot solve the problem, go to the next item.
3. Copy image quality inspection
Make copies and check whether the problem has been solved.
If it has been solved,nish the inspection.
If it remains unsolved, go to the next secton.
