Oki MC561 User Manual

44473001TH Rev.1
206 /
Oki Data CONFIDENTIAL
7. TROUBLESHOOTING PROCEDURES
7.5.2 Service Call List
Display Cause Error details Measure
Inspection is
required.
001 : Error
Machine
Check
Exception
A hardware error was
detected (board failure or
insufficient power supply
capacity).
Replace the CU/
PU board.
Power OFF/ON
002 : Error
～
006 : Error
009 : Error
～
011 : Error
CPU
Exception
Is the error display provided
again?
Yes
No
Remove any RAM
DIMM and turn off and
on the MFP.
Replace the CU/
PU board.
Reinstall the RAM
DIMM.
Inspection is
required.
020 : Error
CU ROM
Hash
Check Error Is the error display provided
again?
Yes
Turn off and on the
MFP.
Replace the CU/ PU
board.
Inspection is
required.
024 : Error
025 : Error
Kanji Font
Error
Inspection is
required.
030 : Error
CU RAM
Check Error
Is the error display provided
again?
Yes
Turn off and on the
MFP.
Replace the CU/ PU
board.
Inspection is
required.
031 : Error
036 : Error
CU optional
RAM check
error
Is RAM DIMM installed
properly?
Does the MFP recover by
replacing the RAM DIMM?
No
Yes
No
Reinstall the RAM
DIMM.
Replace the RAM
DIMM.
Replace the CU/ PU
board.
Inspection is
required.
040 : Error
CU EEPROM
error
Is the error display provided
again?
Yes
Turn off and on the
MFP.
Replace the CU/ PU
board.
Display Cause Error details Measure
Inspection is
required.
041 : Error
CU flash
memory error
or CU board
flash ROM
error
Is the error display provided
again?
Yes
Turn off and on the
MFP.
Replace the CU/ PU
board.
Inspection is
required.
042 : Error
043 : Error.
045 : Error
Flash
memory file
system error
Accessing the flash ROM
directly mounted on the CU/
PU board failed.
Turn off and on the
MFP.
Replace the CU/ PU
board.
Power OFF/ON
052 : Error
processor
driver error Is the error display provided
again?
Yes
Turn off and on the
MFP.
Replace the CU/ PU
board.
Inspection is
required.
064 : Error
SD Card
Missing Error
Inspection is
required.
067 : Error
068 : Error
Interface
monitor error
Inspection is
required.
069 : Error
NIC Chip
Error
Power OFF/ON
070 : Error
PostScript
error
Error is deteced inside the
postscript core
Take note of the
address that is
displayed on LCD.
Turn off and on the
MFP.
Power OFF/ON
072 : Error *.
Engine
interface error
or PU-CU
interface error
Is the CU/PU board installed
properly?
No
Yes
Reinstall the CU/ PU
board properly.
Replace the CU/ PU
board.

Oki MC561 Specifications

Printing Specifications

Print Speed	Up to 27 ppm color, 31 ppm black & white
Time to First Page	As fast as 8 seconds in color, 7.5 seconds in black & white
Print Resolution	Up to 1200 x 600 dpi

Copying Specifications

Copy Speed	Up to 27 cpm color, 31 cpm black & white
First Copy Out	As fast as 14 seconds in color, 12 seconds in black & white
Copy Resolution	Up to 600 x 600 dpi

Scanning Specifications

Scan Type	Color and black & white flatbed
Scan Resolution	Up to 1200 x 1200 dpi
Scan Speed	Approx. 3 sec./page color, approx 2 sec./page black & white at 300 dpi

Fax Specifications

Fax Modem	33.6 Kbps Super G3
Transmission Speed	3 seconds/page
Fax Resolution	Up to 200 x 400 dpi

System Memory

Standard Imaging RAM	256 MB
Max Imaging RAM	768 MB
SD Card Storage	4 GB standard; 16 GB optional

Paper Handling

Scanner RADF Capacity	Up to 50 letter/legal sheets
Standard Input	350 sheets (250 sheets via Main Tray + 100 sheets via MPT)
Maximum Input	880 sheets (with optional 530-sheet 2nd Paper Tray)

Environmental Specifications

Size	16.8" x 20" x 17.5" (42.7 cm x 50.9 cm x 44.4 cm)
Weight	63 lb. (29 kg)
Power Consumption	Operating Normal 570W; Max 1170W; Idle 100W; Power Save 20W; Deep Sleep <1.5W
