7. TROUBLESHOOTING PROCEDURES
No.
Category
PJL Status
Code
Error Warning Description
11 Error 40903 (Y)
40904 (M)
40905 (C)
40902 (K)
1
2
3
4
5
%COLOR% Toner Cartridge not
installed.: %ERRCODE%
Please see Help for details.
The toner cartridge is not
installed.
Error 610 : Y
Error 611 : M
Error 612 : C
Error 613 : K
Four following behavior
is carried out by mode of
operation.
1. Only warning display.
(This error is not displayed).
2. Warning status takes
effect at Cover Open/
Close.
3. With no automatic
concentration
compensation.
4. This error is displayed
and it stops.
12 Error 40960 (Y)
40961 (M)
40962 (C)
40959 (K)
1
2
3
4
5
Please check %COLOR% Toner
Cartridge.: %ERRCODE%
Please see Help for details.
Something is wrong with
the toner sensor.
This status is indicated in
Shipping Mode only.
If the same error is
detected in FACTORY
Mode, it is indicated as
service call of 163.
Error 540 : Y
Error 541 : M
Error 542 : C
Error 543 : K
13 Error 30034 1
2
3
4
5
Paper Size Error
Please open the scanner unit and
the top cover and check paper
size.
Please see Help for details.
Inappropriate size paper
was fed from a tray.
Check the paper in the
tray or check for Multiple-
feed. Open and close the
cover to perform recovery
printing, and continue.
No.
Category
PJL Status
Code
Error Warning Description
14 Error 40077 1
2
3
4
5
Paper Jam: 390
Please open the scanner unit and
the top cover.
Please see Help for details.
Paper Jam occurred
during paper feeding from
tray.
Error 390 : MP Tray
15 Error 40077 1
2
3
4
5
Paper Jam: %ERRCODE%
Please pull out the paper cassette
of the indicated tray.
Please see Help for details.
Paper Jam occurred
during paper feeding from
tray.
Error 391 : Tray1
Error 392 : Tray2
16 Error 40982 1
2
3
4
5
Paper Jam: 380
Please open the scanner unit and
the top cover.
Please see Help for details.
Jam has occurred in
paper path.
Error 380 : Feed
17 Error 40078
40079
40051
40820
1
2
3
4
5
Paper Jam: %ERRCODE%
Please open the scanner unit and
the top cover.
Please see Help for details.
Jam has occurred in
paper path.
Error 381 : Transport
Error 382 : Exit
Error 385 : Around Fuser Unit
18 Error 40819 1
2
3
4
5
Paper Jam: 381
Please open the scanner unit and
the top cover.
Please see Help for details.
Jam has occurred in
paper path.
Error 381 : Transport
19 Error 40052
40053
40055
1
2
3
4
5
Paper Jam: %ERRCODE%
Please open the scanner unit and
the top cover.
Please see Help for details.
Jam has occurred nearby
DUPLEX unit.
Error 370 : Duplex Reversal
Error 371 : Duplex Input
20 Error 40054 1
2
3
4
5
Paper Jam: 372
Please open the scanner unit and
the top cover.
Please see Help for details.
Jam has occurred nearby
DUPLEX unit.
Error 372 :
Mi
sfeed from Duplex

Oki MC561 Specifications

Printing Specifications

Print Speed	Up to 27 ppm color, 31 ppm black & white
Time to First Page	As fast as 8 seconds in color, 7.5 seconds in black & white
Print Resolution	Up to 1200 x 600 dpi

Copying Specifications

Copy Speed	Up to 27 cpm color, 31 cpm black & white
First Copy Out	As fast as 14 seconds in color, 12 seconds in black & white
Copy Resolution	Up to 600 x 600 dpi

Scanning Specifications

Scan Type	Color and black & white flatbed
Scan Resolution	Up to 1200 x 1200 dpi
Scan Speed	Approx. 3 sec./page color, approx 2 sec./page black & white at 300 dpi

Fax Specifications

Fax Modem	33.6 Kbps Super G3
Transmission Speed	3 seconds/page
Fax Resolution	Up to 200 x 400 dpi

System Memory

Standard Imaging RAM	256 MB
Max Imaging RAM	768 MB
SD Card Storage	4 GB standard; 16 GB optional

Paper Handling

Scanner RADF Capacity	Up to 50 letter/legal sheets
Standard Input	350 sheets (250 sheets via Main Tray + 100 sheets via MPT)
Maximum Input	880 sheets (with optional 530-sheet 2nd Paper Tray)

Environmental Specifications

Size	16.8" x 20" x 17.5" (42.7 cm x 50.9 cm x 44.4 cm)
Weight	63 lb. (29 kg)
Power Consumption	Operating Normal 570W; Max 1170W; Idle 100W; Power Save 20W; Deep Sleep <1.5W
