Oki MC561 User Manual

44473001TH Rev.1
203 /
Oki Data CONFIDENTIAL
7. TROUBLESHOOTING PROCEDURES
Error (Disable to restore)
No.
Category
PJL Status
Code
Error Warning Description
1 Error 40712 1
2
3
4
5
Inspection is required.
%ERRCODE%: SIP Error
Indicates that the
processing of Scan Image
Processing contller was
failed.
User must turn Off/ On
the power supply, if this
status occurred.
%ERRCODE%
=1 : RAM Check Error
=2 : Illigal parameters
=3 : Memory Overflow
=4 : Scanner Receiving
Time-out
=5
: Others (Fatal Error
）
2 Error 40724 1
2
3
4
5
Please call service.
Scanner unit failed to detect printer
unit.
Indicates that scanner
and printer is not
connected.
This message is
displayed, if the
communication between
scanner and printer units
could not be started.
User must turn Off/ On
the power supply, if this
status occurred.
3 Error 40714 1
2
3
4
5
SIP Firmware Missing Indicates that the
firmware in board can not
be detected.
No.
Category
PJL Status
Code
Error Warning Description
4 Error - 1
2
3
4
5
Inspection is required.
PU Flash Error
It is shown that PU
firmware has booted in
Loader mode.
If initialization is
completed, it will change
to the status of no.20.
This status may
occur also in a user
environment. When it
occurs, the maintenance
by a maintenance
member is required
(equivalent to S/C).
5 Error - 1
2
3
4
5
Inspection is required.
PU Communication Error
Displays that
communication to PU
firmware failed.
This status may
occur also in a user
environment. When it
occurs, the maintenance
by a maintenance
member is required
(equivalent to S/C).
If this status occurred
during the unit initialinzing
the message is displayed
by English.
6 Error 40978 1
2
3
4
5
%PUFLASH% Flash Error PU flush error (Error
occurs during the
alteration of PU farm or it
failed in the alteration in
PU flush of such as LED
Head information.)
%PUFLASH%
PU
TRAY2
TRAY3
DUPLEX

Oki MC561 Specifications

Printing Specifications

Print Speed	Up to 27 ppm color, 31 ppm black & white
Time to First Page	As fast as 8 seconds in color, 7.5 seconds in black & white
Print Resolution	Up to 1200 x 600 dpi

Copying Specifications

Copy Speed	Up to 27 cpm color, 31 cpm black & white
First Copy Out	As fast as 14 seconds in color, 12 seconds in black & white
Copy Resolution	Up to 600 x 600 dpi

Scanning Specifications

Scan Type	Color and black & white flatbed
Scan Resolution	Up to 1200 x 1200 dpi
Scan Speed	Approx. 3 sec./page color, approx 2 sec./page black & white at 300 dpi

Fax Specifications

Fax Modem	33.6 Kbps Super G3
Transmission Speed	3 seconds/page
Fax Resolution	Up to 200 x 400 dpi

System Memory

Standard Imaging RAM	256 MB
Max Imaging RAM	768 MB
SD Card Storage	4 GB standard; 16 GB optional

Paper Handling

Scanner RADF Capacity	Up to 50 letter/legal sheets
Standard Input	350 sheets (250 sheets via Main Tray + 100 sheets via MPT)
Maximum Input	880 sheets (with optional 530-sheet 2nd Paper Tray)

Environmental Specifications

Size	16.8" x 20" x 17.5" (42.7 cm x 50.9 cm x 44.4 cm)
Weight	63 lb. (29 kg)
Power Consumption	Operating Normal 570W; Max 1170W; Idle 100W; Power Save 20W; Deep Sleep <1.5W
