Maintenance > 118
I
MAGE
DRUM
REPLACEMENT
The MFP contains four image drums: cyan, magenta, yellow and black.
1. Pull the lever (a) firmly to release the lock and then gently raise the scanner (b).
2. Press the cover release (a) and open the top cover (b) fully.
CAUTION!
Static sensitive devices, handle with care.
WARNING!
If the MFP has been powered on, the fuser will be hot. This area is
clearly labelled. Do not touch.
b
a
b
a
