ML1120/ML1190 eco User’s Guide – Operating instructions > 79
A DJUSTING TOF POSITION
Use the following procedure to set TOF to accord with the
reference position (23.28 mm (11/12 in)). The reference position
refers to the first line of the paper i.e. the position to which the
printer feeds the paper when automatically loading the paper.
1. Print out the menu settings of the printer as in
“Confirming current settings” on page 53 and confirm that
the TOF (in cut sheet mode or continuous forms mode) is
23.28 mm (11/12 in).
2. Set the Paper Type lever to the required paper type.
3. When continuous forms are used, place the paper on the
Pin Tractor.
For cut sheet mode, do not insert the paper at this stage.
4. In continuous forms mode, press the LOAD/EJECT button.
In cut sheet mode, place the paper in the Paper Tray and
press LOAD/EJECT.
5. In off-line mode, press the following buttons to adjust the
first printing line:
To feed the paper forward by a small amount, press and
hold down the LOAD/EJECT button and then press the SEL
button.To feed the paper backward by a small amount,
press and hold down the LOAD/EJECT button and then
press the LF/FF button.
When the paper is positioned at the required TOF, release
the buttons in Step 5 above.
NOTE
Adjusting of TOF can be done in cut sheet mode or continuous
forms mode.
NOTE
If the specified correction range is more than +- 3.53mm (20/
144 in) for ML1120 eco and +- 4.23 mm (30/180 in) for
ML1190 eco, the paper cannot be moved.

Oki ML1120 Specifications

General

Noise level	49.7 dB
Maximum duty cycle	18000 pages per month
Maximum number of copies	9 copies
Power requirements	120 - 220V
Dimensions (WxDxH)	889 x 587 x 379 mm

Weight and Dimensions

Dimensions (W x D x H) (imperial)	35 x 23.1 x 14.9 \
