Page: 54
Service Guide ML390/391
Chapter 3 Maintenance & Disassembly
Rev C
NOTES:
The Rev A and B printers do NOT have a cable guide.
The Rev C printers do NOT have a power interconnect module.
Rev C printers have a cable guide.
· Perform these procedures:
3.2.01
,3.2.04 .
· Use a straight-slot screwdriver to release the claws (1) from the chassis clamps (2).
· Remove the cable guide (3).
P/N 51003801 Guide: Cable All RSPL C
B.2.06
To Next Page
