Service Guide ML390/391
Chapter 3 Maintenance & Disassembly
3.2.04 Upper Cover Assembly
·
Perform this procedure: 3.2.01
.
· Wrap a rubber band around the wire extensions of the interface connector. This pulls the extensions in
and avoids damage when the cover is removed. (Not shown).
· Detach the platen knob (1).
· Insert a flat-blade screwdriver through the slots (2) and disengage the claws of the cover. The Microline
390 and Microline 390-Plus have three slots. The Microline 391 and Microline 391-Plus have five slots.
· Lift the front of the upper cover assembly (3) and remove the assembly.
· The upper cover assembly contains the access cover assembly (4), the sheet separator assembly (5),
the rear cover (6), and the middle cover (7)
CAUTION:
Do NOT rotate the access cover past the vertical when removing it. The tab extensions can break.
Before installing the cover, move the bail arm lever towards the back of the printer and move the release
lever towards the front of the printer.
After installation, verify that the cover is correctly seated in the front slots. The cover will warp if it is
incorrectly installed. Check that the paper bail moves properly.
When cleaning, refer to Section 3.4 of this Service Handbook
.
P/N 51901101 Knob: Platen All RSPL A B C
B.2.02
, B.2.03
P/N 50060701 Cover: Access (Assembly) Both 90 RSPL A B C
B.2.01
P/N 50060801 Cover: Access (Assembly) Both 91 RSPL A B C
B.2.01
P/N 50060901 Separator: Sheet (Assembly) Both 90 RSPL A B C
B.2.01
P/N 50061001 Separator: Sheet (Assembly) Both 91 RSPL A B C
B.2.01
P/N 53488501 Frame: Rear Cover Both 90 RSPL A B C
B.2.01
P/N 53488601 Frame: Rear Cover Both 91 RSPL A B C
B.2.01
P/N 53488301 Cover: Middle (ML390) 390 RSPL A B C
B.2.01
P/N 53488316 Cover: Middle (ML390+) 390+ RSPL A B C
B.2.01
P/N 53488401 Cover: Middle (ML391) 391 RSPL A B C
B.2.01
P/N 53488422 Cover: Middle (ML391+) 391+ RSPL A B C
B.2.01
