Oki ML390 - Head Cable Access Cover and Connection Board

Page: 56
Service Guide ML390/391
Chapter 3 Maintenance & Disassembly
3.2.13 Head Cable Access Cover and Connection Board (SRBS)
NOTE:
Remove this cover to provide access when connecting the head cable to the control board.
· Perform these procedures:
3.2.01
,3.2.04 , 3.2.05 , 3.2.06
.
· Slide the carriage frame (1) in the direction of arrow A.
· Pull the connector (2) in the direction of arrow B and remove the connector.
· Release the clamp (3) and detach the head cable (4).
· Release the two claws (5) and remove the head cable access cover (6). The claws are accessed from
the bottom of the printer.
· Pull the board (7) in the direction of arrow B to detach it from the claws (8).
· Remove the board.
P/N 56723801 Conn: Connection AKT-60 All RSPL
B.2.04
P/N 50062301 Cover: Head Cable Access All RSPL A B C
B.2.04
,
B.2.06
P/N 55038501 PCB: SRBS All RSPL
B.2.04
(Connection Board)
