Oki ML390 - Line Feed Motor Interconnect Module

Page: 65
Service Guide ML390/391
Chapter 3 Maintenance & Disassembly
3.2.21 Line Feed Motor Interconnect Module
NOTE:
Use care when performing this procedure. The plastic extension will break if too much pressure is applied.
· Perform these procedures:
3.2.01
,3.2.02 , 3.2.04 , 3.2.05 , 3.2.06 , 3.2.20 .
· Insert a straight-slot screwdriver between the line feed motor interconnect module (1) and the chassis.
Then, carefully pry the module from the two guide holes (2).
P/N 53328401 Module: LF Motor Interconnect All RSPL A B C
B.2.05
, B.2.07
