Service Guide ML390/391
Chapter 3 Maintenance & Disassembly
3.2.14 Ribbon Feed Gear Assembly
CAUTION:
When handling the head cable, do NOT bend the cable at sharp angles or you may damage it.
· Perform these procedures:
3.2.01
,3.2.04 .
· Remove the ribbon (1).
· Insert a straight-slot screwdriver through the access slots and release the two front claws (2) and the two
rear claws (3) of the ribbon feed gear assembly (4).
· Lift and remove the assembly.
· Detach the head cable (5), the cable clamp (not shown) and the contact pressure rubber (6) from the
assembly.
NOTE:
Lubrication
When lubricating, refer to Section 3.5 of this Service Handbook
.
P/N 50061401 Gear: Ribbon Feed (Assembly) All RSPL A B C
B.2.09
P/N 56615403 Cable: Head (Flexible) Both 90 RSPL A B C
B.2.09
P/N 56615404 Cable: Head (Flexible) Both 91 RSPL A B C
B.2.09
P/N 51706501 Rubber: Contact Pressure Both RSPL A B C
B.2.09
P/N 53526701 Rubber: Contact Pressure Both+ RSPL A B C
B.2.09
