Service Guide ML390/391
Chapter 4 Failure & Repair Analysis
4.6 REPAIR ANALYSIS PROCEDURES
4.6.01 Using the RAPs
When using the Repair Analysis Procedures, follow these steps.
· Use the RAP INDEX to find the RAP associated with the printers problem.
· Go to the appropriate RAP.
· All of the RAPs will begin with a START Statement, followed by questions or another type of statement.
· If the RAPs do not lead you to the cause of a problem, please report this to Okidata.
Refer to Section
4.3 for further details .
