Oki ML390 User Manual

Ribbon Drive
Assembly (Visible
bearings of gears)
3.2.14
Machine Oil Small Do NOT lubricate the
teeth of the gears. Do
NOT disassemble the
case.
Space Motor
Assembly Contact
between the
space motor
assembly gear
and the space
rack.
3.2.15
Machine Oil Small Turn the assembly over to
access the point. Do not
over-lubricate. Do NOT
place lubricant directly on
the space rack.
Carriage Shaft
3.2.16
Machine Oil Small Place a small amount on
the surface of the carriage
shaft. Wipe with a soft
lint-free cloth.
Platen Assembly
Contact point
between the bias
gear and the
platen gear.
3.2.19
Machine Oil Small
Idle Gear Bearing
3.2.22
Grease Medium
Change Lever
Bearing and pivot
point
3.2.22
Grease Medium
Pressure Spring
Pivot point of the
release cam.
Holders on the
pressure spring.
Bearing of the
front release arm.
3.2.22
Grease Medium
Tractor Gear
Bearing
3.2.26
Grease Medium
Lower Tractor
Feed Shaft
Contact points
with main chassis
3.2.26
Grease Medium
3.5.06 Areas Not Lubricated
