Oki ML390 User Manual

40 V 1 23 22
0 V 16 12 12
5 V 18 16 16 26
EP 21 - 25 19-2
2
19-2
2
Pin 1 19 19 Approx
. 18.3
ohms
Pins on back
of printhead
Pin 2 2 2
Pin 3 18 18
Pin 4 3 3
Pin 5 35 39
Pin 6 22 22
Pin 7 34 38
Pin 8 23 23
Pin 9 17 17
Pin 10 4 4
Pin 11 16 16
Pin 12 5 5
Pin 13 33 33
Pin 14 24 24
Pin 15 32 32
Pin 16 25 25
Pin 17 13 13
Pin 18 8 8
Pin 19 12 23
Pin 20 9 9
Pin 21 11 11
Pin 22 10 10
Pin 23 29 29

Oki ML390 Specifications

General

Brand	Oki
Model	ML390
Category	Printer
Language	English
