Page: 115
Service Guide ML390/391
Chapter A Board Diagrams
Microline 390/391: Rev C
Description
Board Designation
Section
Control Board SKRA-3
A.2.02
Power Supply SUII
A.2.04
Filter Assembly N/A
A.2.05
Operator Panel LXSP
A.2.06
Interconnect Board SRBS
A.2.08
RS232-C Serial Interface LXHI
A.2.09
