Item Okidata P/N Oki-J
P/N
Description Produ
ct
Commen
ts Refer
to B.1.02
Disassemb
ly
Procedure
Serial
No. Rev.
Letter
32 B 51219001
3PB4055-2440P1
Gear: Line
Feed Motor
All RSPL 3.2.20 A B C
32 56507003
3PB4025-2844P3
Motor: Line
Feed
All RSPL
3.2.20
A B C
25 53328401
3PP4025-2874P1
Module: LF
Motor
Interconnect
All RSPL 3.2.21 A B C
41 B 58227501
N/A
Kit:
Idler/Change
Gear (ML300)
All RSPL
Inc. 39
and 41
3.2.22 A B C
39 51216001
4PP4025-2868P1
Idler Gear All 3.2.22 A B C
41 51215901
4PP4025-2866P1
Change Gear All 3.2.22 A B C
40 50912001
4PP4025-2867P1
Spring: Reset All RSPL 3.2.22 A B C
37 53489501
3PP4025-2852P1
Lever:
Release
All RSPL 3.2.23 A B C
18 50911501
3PP4025-2819P1
Guide: Paper
Pressure
Both
90
RSPL 3.2.24 A B C
18 50911601
3PP4025-2905P1
Spring:
Release
391 RSPL 3.2.24 A B
18 50911602 Guide: Paper
Pressure
Both
91
RSPL 3.2.24 C
95 50913901
3PP4025-3161P1
Spring:
Support
391+ RSPL 3.2.24 A B C
36 50061801
3PA4025-2853G1
Chute: Paper
(Assembly)
Both
90
RSPL 3.2.25 A B C
36 50061901
3PA4025-2915G1
Chute: Paper
(Assembly)
Both
91
RSPL 3.2.25 A B C
38 53489601
4PP4025-2881P1
Link: Release All RSPL 3.2.25 A B C
35 50061601
3PA4025-2846G1
Roller:
Pressure
(Assembly)
Both
90
RSPL 3.2.25 A B C
