Oki PT390 - Page 12

11
Insert
Connector cover
Insert
For a unit with Dual interface
Serial interface cable
* Secure the connector with
screws after making the
connection.
USB Interface Cable
Type-B
* Connect the printer to a PC
through this connector.
Interface connector
(Serial interface)
Interface Connector
(USB Interface Type-B)
* Connect the printer to a PC
through this connector.
Power connector
Drawer kick connector
