C-5.Sample Print
With paper inserted in the printer, turn off the printer power switch once. If
you turn on the switch again while holding down the FEED switch on the
control panel, the data shown in Section C-1 will be printed. If you turn on the
switch again and press the FEED switch briefly, the data shown below will be
printed.
When "SAMPLE PRINT" is printed, press and hold down the FEED switch for
one second or longer to place the printer in sample print mode.
The printed pattern is as follows.
a) Receipt pattern
b) Coupon pattern
c) Barcode pattern
When the FEED switch is pressed short, the following pattern is printed.
“Receipt” “Coupon” “Barcode” “Receipt”・・・・・・
When the FEED switch is pressed long (about one second), the same pattern
is printed again.
The printed pattern is changed by setup "Paper Width" setting.
83mm/53columns -> Pattern 80mm
80mm/48columns -> Pattern 80mm
80mm/42columns -> Pattern 80mm
60mm/36columns -> Pattern 58mm
58mm/35columns -> Pattern 58mm
58mm/32columns -> Pattern 58mm
The sample print mode is ended by the printer power supply determination.
SAMPLE PRINT
↑
CUTTER CLEANING
↑
PLATEN ROLLER CLEANING
↑
SET UP
↑
HEX DUMP
↑
TEST PRINT
ITEM SELECTION :FEED switch pushed short.
ITEM DECSION :FEED switch pushed short.
SPECIAL MODE
Paper feed direction
END
SAMPLE PRINT
CUTTER CLEANING
PLATEN ROLLER CLEAING
SET UP
HEX DUMP
TEST PRINT
SELECTION ITEM
