Appendix A: Specifications
A-1.General Specifications
(1) Print method: Direct line thermal printing system
(2) Maximum print speed: 260mm/s (single-color thermal paper)
115mm/s (two color thermal paper)
(3) Dot resolution: 8 dots/mm (0.125mm)
(4) Relationship between number of print columns and character size
Body Face
Body Face
For paper 58mm wide
For paper 60mm wide
32 column printing
35 column printing
36 column printing
ANK: Font A
32 columns: 12x24
35 columns: 12x24
36 columns: 12x24
ANK: Font B
38 columns: 10x24
42 columns: 9x24
42 columns: 10x24
46 columns: 9x24
43 columns: 10x24
48 columns: 9x24
ANK: Font C
48 columns: 8x16
52 columns: 8x16
54 columns: 8x16
Kanji: Font A
16 columns: 24x24
17 columns: 24x24
18 columns: 24x24
Kanji: Font B
19 columns: 20x24
21 columns: 20x24
21 columns: 20x24
Kanji: Font C
24 columns: 16x16
26 columns: 16x16
27 columns: 16x16
ANK: Font A
Extension Font
32 columns: 12x24 35 columns: 12x24 36 columns: 12x24
ANK: Font B
Extension Font
38 columns: 10x24
42 columns: 9x24
42 columns: 10x24
46 columns: 9x24
43 columns: 10x24
48 columns: 9x24
For paper 80mm wide
For paper 83mm wide
42 column printing
48 column printing
53 column printing
ANK: Font A
42 columns: 12x24
48 columns: 12x24
53 columns: 12x24
ANK: Font B
51 columns: 10x24
56 columns: 9x24
57 columns: 10x24
64 columns: 9x24
64 columns: 10x24
71 columns: 9x24
ANK: Font C
64 columns: 8x16
72 columns: 8x16
80 columns: 8x16
Kanji: Font A
21 columns: 24x24
24 columns: 24x24
26 columns: 24x24
Kanji: Font B
25 columns: 20x24
28 columns: 20x24
32 columns: 20x24
Kanji: Font C
32 columns: 16x16
36 columns: 16x16
40 columns: 16x16
ANK: Font A
Extension Font
42 columns: 12x24 48 columns: 12x24 53 columns: 12x24
ANK: Font B
Extension Font
51 columns: 10x24
56 columns: 9x24
57 columns: 10x24
64 columns: 9x24
64 columns: 10x24
71 columns: 9x24
