Olivetti d-Copia 2000 Service Manual

2HA/2HB
1-4-4
Paper con-
veying sec-
tion
23 Multiple sheets in the
drawer 3* (second paper
feeder)
The drawer feed switch 1 (DFSW1)* does not turn off within
6320 ms of drawer feed switch 1 (DFSW1)* turning on.
The drawer feed switch 1 (DFSW1)* does not turn off within
2560 ms of drawer paper feed clutch 2 (DPFCL2)* turning on.
24 Multiple sheets in the
drawer 4* (third paper
feeder)
The drawer feed switch 2 (DFSW2)* does not turn off within
6320 ms of drawer feed switch 2 (DFSW2)* turning on.
The drawer feed switch 2 (DFSW2)* does not turn off within
2560 ms of drawer paper feed clutch 3 (DPFCL3)* turning on.
Transfer
section
30 Misfeed in registration/
transfer section
The registration switch (RSW) does not turn off within 2340 ms
of drawer feed switch 1 (DFSW1)* turning on.
The registration switch (RSW) does not turn off within 2340 ms
of drawer feed switch 1 (DFSW1)* turning off.
The registration switch (RSW) does not turn off within 1760 ms
of duplex paper conveying switch (DUPPCSW1)* turning on.
Fuser sec-
tion
40 Misfeed in the fuser sec-
tion (paper feed from MP
tray)
The exit switch (ESW) does not turn on within 3020 ms of the
registration motor (RM) turning on.
41 Misfeed in the fuser
section (paper feed from
drawer)
The exit switch (ESW) does not turn on within 3020 ms of the
registration motor (RM) turning on.
42 Misfeed in the fuser
section* (paper feed from
first paper feeder)
The exit switch (ESW) does not turn on within 3020 ms of the
registration motor (RM) turning on.
43 Misfeed in the fuser
section* (paper feed from
second paper feeder)
The exit switch (ESW) does not turn on within 3020 ms of the
registration motor (RM) turning on.
44 Misfeed in the fuser
section* (paper feed from
third paper feeder)
The exit switch (ESW) does not turn on within 3020 ms of the
registration motor (RM) turning on.
45 Misfeed in the fuser
section* (paper feed from
duplex section)
The exit switch (ESW) does not turn on within 3020 ms of the
registration motor (RM) turning on.
Exit section 50 Misfeed in the exit section The exit switch (ESW) does not turn off within 3020 ms of the
registration switch (RSW) turning off.
The exit switch (ESW) does not turn on within 3020 ms of the
registration motor (RM) turning on.
Feedshift
section
52 Misfeed in the feedshift
section (paper feed from
MP tray)
The feedshift switch (FSSW) does not turn off within 6320 ms
of feedshift switch (FSSW) turning on.
The feedshift switch (FSSW) does not turn off within 1530 ms
of paper switchback.
The feedshift switch (FSSW) does not turn on within 1530 ms
of paper switchback.
53 Misfeed in the feedshift
section (paper feed from
drawer)
The feedshift switch (FSSW) does not turn off within 6320 ms
of feedshift switch (FSSW) turning on.
The feedshift switch (FSSW) does not turn off within 1530 ms
of paper switchback.
The feedshift switch (FSSW) does not turn on within 1530 ms
of paper switchback.
*: Optional.
Section Jam code Description Conditions
