Olivetti d-Copia 2000 Service Manual

2HA/2HB
1-5-27
1-5-6 Transfer section
(1) Detaching and refitting the transfer roller
Follow the procedure below to replace the transfer roller.
Procedure
1. Remove the paper conveying unit (see page
1-5-7).
2. Remove the screw holding each of the front
and rear release lever stoppers and then the
stoppers from the release lever shaft.
Figure 1-5-56
3. Detach the fitting portions located
on the front and rear and then
remove the transfer roller from the
paper conveying unit.
4. Replace the transfer roller and
refit all the removed parts.
Figure 1-5-57
Paper conveying unit
Rear release
lever stopper
Front release
lever stopper
Transfer roller
Fitting portion
Fitting portion
Paper conveying unit
