Olivetti d-Copia 2000 Service Manual

2HA/2HB
1-5-31
(3) Detaching and refitting the fuser heater M and S
Follow the procedure below to replace the fuser heater M and S.
Procedure
1. Remove the fuser unit and separate the
fuser right unit and left unit (see pages 1-5-
28, 30).
2. Remove the two screws holding each of the
fuser heater M and S on the front and rear of
the fuser left unit.
Figure 1-5-65
3. Pull out the fuser heater M and S from the
fuser left unit.
4. Replace the fuser heater M and S, and refit
all the removed parts.
Figure 1-5-66
Fuser heater M
Fuser heater M
Fuser heater S
Fuser heater S
Fuser heater S
Fuser heater M
