Olivetti d-Copia 2000 Service Manual

2HA/2HB
1-4-11
(16)
A paper jam in the
exit section is indi-
cated during copying
(misfeed in the exit
section).
Jam code 50
Broken registration switch
or exit switch actuator.
Check visually and replace the registration switch or exit switch if
its actuator is broken.
Defective registration
switch or exit switch.
Run maintenance item U031 and turn each switch on and off
manually. Replace the corresponding switch if indication of switch
is not light.
Check if the registration
motor malfunctions.
Run maintenance item U030 and select the registration motor to
be turned on and off. Check the status and remedy if necessary.
Electrical problem with the
registration motor.
Check (see page 1-4-26).
(17)
A paper jam in the
feedshift section is
indicated during
copying (misfeed in
the feedshift section).
Jam code 52, 53, 54,
55, 56
Broken feedshift switch
actuator.
Check visually and replace the feedshift switch if its actuator is
broken.
Defective feedshift switch. Run maintenance item U031 and turn feedshift switch on and off
manually. Replace feedshift switch if indication of switch is not
light.
Check if the exit motor mal-
functions.
Run maintenance item U030 and select the exit motor to be
turned on and off. Check the status and remedy if necessary.
Electrical problem with the
exit motor.
Check (see page 1-4-26).
(18)
A paper jam in the
duplex section is indi-
cated during copying
(misfeed in duplex
paper conveying sec-
tion).
Jam code 60
Broken feedshift switch
actuator.
Check visually and replace the feedshift switch if its actuator is
broken.
Defective feedshift switch. Run maintenance item U031 and turn feedshift switch on and off
manually. Replace feedshift switch if indication of switch is not
light.
Broken duplex paper con-
veying switch actuator.
Check visually and replace the duplex paper conveying switch if
its actuator is broken.
Defective duplex paper con-
veying switch.
Run maintenance item U031 and turn duplex paper conveying
switch on and off manually. Replace duplex paper conveying
switch if indication of switch is not light.
Check if the exit motor mal-
functions.
Run maintenance item U030 and select the exit motor to be
turned on and off. Check the status and remedy if necessary.
Electrical problem with the
exit motor.
Check (see page 1-4-26).
Check if the duplex feed
clutch malfunctions.
Check visually and remedy if necessary.
Electrical problem with the
duplex feed clutch.
Check.
Problem
Causes/check procedures Corrective measures
