2HA/2HB
2-3-11
YC7 1 +24V4 O 24 V DC power supply for DM
Connected
to the drive
motor
2 PGND - Ground
3 SGND - Ground
4 +5 V O 5 V DC power supply for DM
5REM ODM on/off
6 RDY I DM rotation sync signal
7 CLK O DM clock signal
YC8 1 BPPESW I MPPSW on/off
Connected
to the
drawer PWB
2 C1PDSWN I PSW on/off
3 FCLTN O PFCL on/off
4 +24V1 O 24 V DC power supply for DPWB
5 BPSOLN O MPPFCL on/off
6 ICLTN O DUPFCL on/off
7 IPPSWN I DUPPCSW on/off
8 BPWSW I MPPWSW on/off
9 REGSWN I RSW on/off
10 TONEPY I TCS on/off
11 SGND - Ground
12 +5 V2 O 5 V DC power supply for DPWB
13 C1PWSWN I PWSW on/off
14 HUMIDC I HUMSENS analog signal
15 HMCLK2 O HUMSENS clock signal (2)
16 HMCLK1 O HUMSENS clock signal (1)
17 TEMP I HUMSENS analog signal
YC9 1 DHVCLK O Developing bias clock signal
Connected
to the high
voltage
PWB
2 +5 V O 5 V DC power supply for HVTPWB
3 SHVISELN O Separation high-voltage switch signal
4 PGND - Ground
5 MHVDRN O Main charging high-voltage on/off
6 PGND - Ground
7 SHVDRN O Separation high-voltage on/off
8 PGND - Ground
9 MHVADJ O Main charging high-voltage adjust signal
10 PGND - Ground
11 THVDRN O Transfer high-voltage on/off
12 +24 V4 O 24 V DC power supply for HVTPWB
13 THVADJ O Transfer high-voltage adjust signal
14 +24 V4 O 24 V DC power supply for HVTPWB
15 MHVISELN O Main charging high-voltage switch signal
16 +24 V4 O 24 V DC power supply for HVTPWB
YC10 1 LOPSRDY I Paper feeder READY signal
Connected
to the
optional
paper feeder
2 LOPSEL2 O Paper feeder SEL2 signal
3 LOPSEL1 O Paper feeder SEL1 signal
4 LOPSEL0 O Paper feeder SEL0 signal
5 LOPSCLK O Paper feeder clock signal
6 LOPSDI I Paper feeder serial communication reception
7 LOPSDO O Paper feeder serial communication transmission
8 SGND - Ground
9 +5 V2 O 5 V DC power supply for the paper feeder
10 SGND - Ground
11 +5 V2 O 5 V DC power supply for the paper feeder
Connector Pin No. Signal I/O Description
