2HA/2HB
2-3-18
Connector Pin No. Signal I/O Description
YC1 1 SGND - Ground
Connected
to the main
PWB
2 SH I MPWB SH signal
3 SGND - Ground
4 CP I MPWB CP signal
5 SGND - Ground
6 RS I MPWB RS signal
7 SGND - Ground
8 CCDCLKN I CCDCLKN signal
9 SGND - Ground
10 CCDCLK I CCDCLK signal
11 SGND - Ground
12 +12 V I 12 V DC power supply from MPWB
13 SGND - Ground
14 +5 V I 5 V DC power supply from MPWB
15 CCDEN O CCDPWB image scanning signal
16 CCDE - Ground
17 CCDON O CCDPWB image scanning signal
18 CCDO - Ground
