14
Names of parts
Playback mode
• The indications that appear on a movie picture that has been
selected and displayed from the index display are different from
those that appear when the movie picture is displayed using the
movie playback function.
Still picture Movie
Item Indications
Ref.
Page
1 Battery check e, f
P.15
2 Switch frame J
P.131
3 Print reservation,
Number of prints
Movie
< × 10
n
P.159
P.118
4 Sound record H
P.93
5Protect 9
P.130
6 Record mode TIFF, SHQ, HQ, SQ1, SQ2
P.95
7 Resolution 2048 × 1536, 1280 × 960, 640 × 480,
320 × 240 etc.
P.97
8 Aperture value F2.8 – F8.0
P.65
9 Shutter speed 15" – 1/1000
P.66
10 Exposure
compensation
-2.0 – +2.0
P.101
11 White balance WB AUTO, 5, 3, 1, w, x, y, V
P.102
12 ISO ISO 100, ISO 200, ISO 400
P.100
13 Date and time ’04.02.17 15:30
P.28
14 File number, Frame
number
Playing time/
Total recording time
FILE : 100 – 0030, 30
00:00/00:20
P.153
'04.02.17 15:30
'04.02.1
7
15:30
00:00/00:20
6
7
11
13
14
12 345
Note
To Next Page
