15
Names of parts
Memory gauge
The memory gauge lights up when you take a still
picture. While the gauge is lit, the camera is
storing the picture on the card. The memory
gauge indication changes as shown below
depending on the shooting status. The indication
is not displayed during movie recording.
Battery check
If the remaining battery power is low, the battery check indication changes as
follows when the camera is turned on or while the camera is in use.
F2.8
1600 1200
SQ1
Memory gauge
Battery check
Before
shooting
(Gauge is off)
No more pictures
can be taken
(Fully lit)
Wait until the gauge
returns to the status
on the left to take
the next shot.
One picture
taken
(Lit)
Two or more
taken
(Lit)
Shoot Shoot Shoot
Wait
a b c d
ef
Lights (green)
(Goes off after a while)
Remaining power level:
high
Remaining power level:
exhausted
Charge the battery.
Blinks (red)
Remaining power level:
low
Charge the battery.
BATTERY EMPTY
is displayed.
