Olympus OmniScan SX - Page 71

DMTA-20043-01EN [U8778624], Rev. B, May 2013
Connector References 63
3In DIN1/
Preset1
Digital input 1/preset
axis 1.
Programmable input.
Can be configured as
generic input 1, or as
the preset of encoder 1.
Refer to the
OmniScan MXU
Software User’s Manual
(“Configuring the
Digital Input” section)
for information on
programming this
input.
To preset, you must use
a high-level signal with
a minimum signal
length of 50 ms.
N/A TTL
4In DIN2/
Preset2
Digital input 2/preset
axis 2.
Programmable input.
Can be configured as
generic input 2, or as
the preset of encoder 2.
Refer to the
OmniScan MXU
Software User’s Manual
(“Configuring the
Digital Input” section)
for information on
programming this
input.
To preset, you must use
a high-level signal with
a minimum signal
length of 50 ms.
N/A TTL
Table 12 Pinout for the scanner interface LEMO connector (continued)
Pin I/O Signal Description Current Level
