Olympus OmniScan SX - Page 72

DMTA-20043-01EN [U8778624], Rev. B, May 2013
64 Chapter 7
5InDIN3/
AcqEn
Digital
input 3/acquisition
enable.
Programmable input.
Can be configured as
generic input 3, or as
an acquisition-enabled
signal (enabled at a
high level with a
minimum signal length
of 50 ms). By default,
configured as generic
input 3. Refer to the
OmniScan MXU
Software User’s Manual
(“Configuring the
Digital Input” section)
for information on
programming this
input.
N/A TTL
Table 12 Pinout for the scanner interface LEMO connector (continued)
Pin I/O Signal Description Current Level
