DMTA-20043-01EN [U8778624], Rev. B, May 2013
Connector References 65
6 In DIN4 Digital input 4/external
pace input.
Programmable input.
Can be configured as
generic input 4, or as
an external pace input
(high level with a
minimum signal length
of 50 ms when used as
DIN4, or 21 µs as
ExtPace).
Refer to the
OmniScan MXU
Software User’s Manual
(“Configuring the
Digital Input” section)
for information on
programming this
input.
N/A TTL
7OutDOUT1/
PaceOut
Digital out 1/pace
output.
±15 mA TTL
8 Out DOUT2 Digital output 2 ±15 mA TTL
9 In PhA axis 1 Encoder 1:
phase A/clock/up/
down.
N/A TTL
10 In PhB axis 1 Encoder 1:
phase B/direction/
N.U./N.U.
a
N/A TTL
11 In PhB axis 2 Encoder 2:
phase B/direction/
N.U./N.U.
N/A TTL
Table 12 Pinout for the scanner interface LEMO connector (continued)
Pin I/O Signal Description Current Level
