Olympus STM7 User Manual

79
STM7
Setting values in the maker setting mode must be inputted by Olympus.
Do not change the setting values by yourselves.
The work to solve the problems caused by changing the setting values are for compensation.
Setting
Items
Display X
Setting Items
Setting Values
Display Y
Setting Values Remark
1 X-axis counting direction 0* Move the stage to left: Positive Do not change unless
necessary.
(It is not necessary to
set at delivery.)
1 Move the stage to right: Positive
2 Standard value of X-axis 000.0001* to
999.9999 mm
Value described in Certificate of
Accuracy
3 Measured value of X-axis 000.0001* to
999.9999 mm
Value described in Certificate of
Accuracy
4 Y-axis counting direction 0* Move the stage to front: Positive Do not change unless
necessary.
(It is not necessary to
set at delivery.)
1 Move the stage to back: Positive
5 Standard value of Y-axis 000.0001* to
999.9999 mm
Value described in Certificate of
Accuracy
6 Measured value of Y-axis 000.0001* to
999.9999 mm
Value described in Certificate of
Accuracy
7 Z-axis counting direction 0* Move the focusing unit up: Positive Do not change unless
necessary.
(It is not necessary to
set at delivery.)
1 Move the focusing unit down: Positive
8 Standard value of Z-axis 000.0001* to
999.9999 mm
Value described in Certificate of
Accuracy
9 Measured value of Z-axis 000.0001* to
999.9999 mm
Value described in Certificate of
Accuracy
10 Loading setting values 0 No
1 Yes
11 Saving setting values 0 No At delivery, after
inputting the setting
values, be sure to
select [1: Save] and
exit.
1 Yes
12 Exit 0 No
1 Yes
* Initial value
1
Maker setting mode
2
Setting Function List
