Digital indicator STM7-DI
Item Specifications
Number of axes 3-axis (X,Y,Z)
Unit μm/mm/inch/mil
Minimum resolution 0.1 μm
Show/Hide minimum
digit
0.1 μm(0.01 mil)/1 μm(0.1 mil)
Display range ±999.9999 mm, ±39.37007 inch
Button functions Reset counter data of X-,Y- and Z-axis
Output counter data of X-,Y- and Z-axis
Indicator Z LIMIT ON: The lower software limit of the focus area is set.
OFF: The lower software limit of the focus area is not set.
COUNT FULL ON: The counter data of X, Y and Z axes is displayed normally.
HALF ON: The counter data of X, Y and Z axes is displayed by 1/2 against the actual movement.
AF TRACK blinks: The autofocusing is being stopped in Track mode.
TRACK ON: The autofocusing is being operated in Track mode.
SHOT blinks: The autofocusing is being stopped in ONE SHOT mode.
SHOT ON: The autofocusing is being operated in ONE SHOT mode.
FOCUS COARSE ON: The movement distance of the fine/coarse focusing knob of the focus controller STM7-
MCZ is large.
FINE ON: The movement distance of the fine/coarse focusing knob of the focus controller STM7-
MCZ is small.
EPI
(green)
ON: The reflected light illumination is turned ON.
OFF: The reflected light illumination is turned OFF.
EPI
(orange)
ON: The reflected light illumination can be controlled.
OFF: The reflected light illumination cannot be controlled.
DIA
(green)
ON: The transmitted light illumination is turned ON.
OFF: The transmitted light illumination is turned OFF.
DIA
(orange)
ON: The transmitted light illumination can be controlled.
OFF: The transmitted light illumination cannot be controlled.
FN
(green)
ON: The illumination for the focus navigator unit is turned ON.
OFF: The illumination for the focus navigator unit is turned OFF.
FN
(orange)
ON: The illumination for the focus navigator unit can be controlled.
OFF: The illumination for the focus navigator unit cannot be controlled.
Dimensions 226(W)x154(H)x50(D) mm
Weight 1.5 kg
Hand switch STM7-HS
Item Specifications
Button functions Illumination control
Reset counter data of X-,Y- and Z-axis
Output counter data of X-,Y- and Z-axis
Memorize/load light intensity value and objective magnification
Counting of counter data in-half
Dimensions 147(W)x32(H)x109(D) mm
Weight 0.3 kg
