STM7
Reflected Light Arm/Reflected Light Illuminator
Item
Specifications
MM6C-VL MM6C-KMAS MM6C-RLAS
Optical system UIS2 (UIS) optics (infinity connection)
Observation methods · Reflected light brightfield · Reflected light brightfield
· Reflected light DIC
· Reflected light simplified
polarized light
· Reflected light brightfield
· Reflected light DIC
· Reflected light simplified
polarized light
Light source · Light guide: White LED for reflected light illumination
Color temperature: Max:8000K, Min:5000K
Dimensions: Ø24x81.7 mm (cable length 1500 mm)
Weight: 80 g
Average life: Approx. 30000 hours (Ambient temperature 20 °C, light
intensity level 50%)
Revolving nosepiece U-5RE-2, U-D6RE, U-5RES-ESD U-5BDRE, U-D5BDRE,
U-D5BDRES-ESD
Applicable objectives · MM6-OB series
· UIS2 (UIS) brightfield
metallurgical objectives (used
in combination with adapter
BD-M-AD)
· UIS2 (UIS) brightfield
metallurgical objectives
· Measurement objectives
(used in combination with
adapter to mount measuring
objectives STM7-MMOBAD)
· UIS2 (UIS) brightfield
metallurgical objectives
· Measurement objectives
(used in combination with
adapter to mount measuring
objectives STM7-MMOBAD)
Dimensions 119(W)x148(D)x95(H) mm 241(W)x148(D)x128.5(H) mm 261(W)x158(D)x128.5(H) mm
Weight Approx. 2.6 kg Approx. 2.6 kg Approx. 3.1 kg
Observation tube
Item
Specifications
MM6-EMO MM6-ETR U-TLU
Image orientation Erect image
Eyepiece tilting angle Fixed at 30°
Interpupillary distance
adjustment range
56 to 76 mm
Light path selection 2 options, binocular 100% or photo 100%
Applicable objectives · MM6-OCC10X (with cross
hairs & helicoids, power 10X,
field number 22)
· MM6-OCC10X (with cross hairs &
helicoids, power 10X, field number 22)
· MM6-OC10X (with helicoids, power
10X, field number 22)
Dimensions 120(W)x188(D)x112(H) mm 160(W)x143(D)x104(H) mm Ø60x64 mm
Weight 1.5 kg 3 kg 0.35 kg
Objectives (MM6-OB Series)
Item
Specifications
MM6-OB1X MM6-OB3X-2 MM6-OB5X MM6-OB10X
Magnification 1X 3X 5X 10X
Working distance (mm) 59.6 76.8 65.4 50.5
Actual field (mm) 22.0 7. 3 4.4 2.2
Number of aperture 0.03 0.09 0.13 0.2
Total magnification error ±0.4%
