Microscope digital camera DP22/DP27
Refer to the instruction manual provided with the microscope digital camera DP22/DP27.
Adapter to mount measuring objective STM7-MMOBAD
Item Specifications
Dimensions Ø60x40(H) mm
Weight 0.7 kg
Anti vibration plates STM7-VI
Item Specifications
Dimensions Ø90x24(H) mm
Weight 3.7 kg
Focus navigator unit STM7-FN
Item Specifications
1. Main unit
Detection method Adjusts the line of projected the reticle
Applicable objective LMPLFLN10X-50X
LMPLFLN-BD10X-50X
MPLFLN10X/MPLFLN-BD10X
MPLN10X/MPLN-BD10X
LMPLFL10X-50X
LMPLFL10X-50XBD
UMPLFL10XBD2
MPL10X/MPL10XBD
MM6-OB10X
Focusing repeatability 10X: 3.5 μm
20X: 1 μm
50X: 0.7 μm
} The experimental value by the mirror sample
Applicable observation
methods
Reflected light brightfield observation, Reflected light darkfield observation
Dimensions 105.5(W)x137.5(D)x51(H) mm
Weight Approx. 1 kg
2. Green LED unit
LED color Green
Dominant wavelength Max: 550nm
Min: 520nm
Dimensions Ø24x83 mm
Cable length: 1500 mm
Weight 80 g
Average life Approx. 30000 hours (Ambient temperature 20°C, light intensity level 50%)
Control box STM7-CB/STM7-CBA
Refer to the instruction manual provided with the control box STM7-CB/STM7-CBA.
Autofocus unit STM7-AF
Refer to the instruction manual provided with the autofocus unit STM7-AF.
